Product Details
Place of Origin: China
Brand Name: KAEMI or GM(Self-owned Brand)
Certification: CE,CCC,ISO9001,etc
Model Number: GM-190H2-2
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD799-999/Set
Packaging Details: Professional Wooden Case or Strong Carton for Import and Export(with Official Chop)--Hot Selling 190cm Width Gross Weight 100Kg, Volume 0.7CBM--Wooden Case Dimension 275*43*51cm(For Reference, Real Figure more or less)
Delivery Time: 2-5 Working Days
Payment Terms: T/T,Trade Assurance Order on Alibaba(All Payment method Supported on Alibaba Available)
Supply Ability: 1000 Sets Per Month
Condition: |
New |
Materials: |
Aluminium Allloy And Stainless Steel |
Function: |
Garment Paper Pattern Graph Contour Printing Plotter Inket Printing Plotter |
Printing Head: |
Dual Head HP45 Ink Cartridges Type, Four Head Optional |
Printing Speed: |
About 90 Square Meters Per Hour For 2 Head, Four Head 160 Square Meters Per Hour |
Cutting Function: |
Cutting Down Function Optional, Cut Down Or Cut Off-Final Cut Only |
Connection Method: |
Cable Direct Connection, Both USB Or LAN Cable |
Printing Materials: |
Newspaper Paper Paper Rolls Kraft Paper Etc |
Application Areas: |
Garment, Shoes, Bags, Furniture, Advertising, Etc |
Printing Width: |
120cm/165cm/185cm/205cm/220cm Optional, Hot Selling 185cm And 205cm Width Version |
Software: |
Independent Cutter Software, Compatible With All CAD Editing Softwares |
Warranty: |
1 Year For Whole Machines, Lifetime Maintenance Service |
Term Of Delivery: |
Exw, FCA, CNF, CIF, FOB, DDP All Support |
Company Features: |
Listed Brand In CCTV, High Tech Enterprise In China |
Aftersales: |
5-6 Person Aftersales Team, 24 Hours Onlines Service |
Distributors Or Agents: |
50+ Agents Or Distributors All Over The World |
Condition: |
New |
Materials: |
Aluminium Allloy And Stainless Steel |
Function: |
Garment Paper Pattern Graph Contour Printing Plotter Inket Printing Plotter |
Printing Head: |
Dual Head HP45 Ink Cartridges Type, Four Head Optional |
Printing Speed: |
About 90 Square Meters Per Hour For 2 Head, Four Head 160 Square Meters Per Hour |
Cutting Function: |
Cutting Down Function Optional, Cut Down Or Cut Off-Final Cut Only |
Connection Method: |
Cable Direct Connection, Both USB Or LAN Cable |
Printing Materials: |
Newspaper Paper Paper Rolls Kraft Paper Etc |
Application Areas: |
Garment, Shoes, Bags, Furniture, Advertising, Etc |
Printing Width: |
120cm/165cm/185cm/205cm/220cm Optional, Hot Selling 185cm And 205cm Width Version |
Software: |
Independent Cutter Software, Compatible With All CAD Editing Softwares |
Warranty: |
1 Year For Whole Machines, Lifetime Maintenance Service |
Term Of Delivery: |
Exw, FCA, CNF, CIF, FOB, DDP All Support |
Company Features: |
Listed Brand In CCTV, High Tech Enterprise In China |
Aftersales: |
5-6 Person Aftersales Team, 24 Hours Onlines Service |
Distributors Or Agents: |
50+ Agents Or Distributors All Over The World |
Main Features:
High-speed Servo Control, Full Closed-loop Positioning (to Ensure Accurate Output of Various Unexpected Situations)
Independent Output Manager Supports File Background Automatic Queuing Printing
Using advanced SOPC technology
Support breakpoint resume, ensure reliable data transmission and printing
Automatic printing online
2 Printing Heads/3 Printing Heads/4 Printing Heads Optional
Technical Parameters | Dual Head Type(2 Ink Boxes) | Four Head Type(4 Ink Boxes) |
Product Model | GM170-2/GM190-2/GM200-2/GM220-2/GM230-2 | GM190-4/GM200-4/GM220-4/GM230-4 |
Printing Width(cm) | 165/185/195/215/225 Maximum Width | 180/190/210/220 Maximum Width |
Feeding Paper Width(cm) | 170/190/200/220/230 Maximum Width | 190/200/20/230 Maximum Width |
Printing Speed | Two-way High Speed 93 sqm/h; | Two-way High Speed 163 sqm/h |
Printing format | HPGL Drawing Language, Compatible with Domestic and Foreign CAD Software, Special format can be Customized | |
Print resolution | 150-600DPI | |
Type of Nozzle | HP45A--2Pcs(Dual Head); 4Pcs(Four Head) | |
Line quality | Clear, Smooth, No Seam, Optional 1-8 Lines | |
Nozzle Cleaning | Automatic Cleaning Before Printing | |
Paper Loading | Front Heightening Device to Support Paper Roll with Diameter of 28cm | |
Paper Feeding | Hidden Infrared Precise Paper Feeding System, Continuous 700 Meters without Deviation | |
Receiving and Delivering Paper | Unattended Automatic Paper Receiving and Feeding | |
Print Media | 40-80g, Ordinary Roll Printing Paper;80-250g, Single Brown Paper | |
Communication Interface | Network Port, Multiple Computers can Separately Control Printing | |
Power Supply Voltage | 220V/50Hz, 110V, 60Hz Optional | |
Button Panel | Press the Keys Operation,Simple, Convenient, Durable | |
Machine Structure | Die Standardized Metal Structure, High Precision and Long Life | |
Output Center | 1.Support Manual or Automatic Printing 2.Optional Ink-saving Mode 3.Support Online Printing |
Since its establishment, GEMEI has developed a series of cutting machines for clothing, bags, shoes and hats, and obtained a number of software copyright and patent certificates. Based on the profound understanding of China’s garment, luggage and footwear industry, GM series of cutting machine combines the essence of Chinese and foreign technologies, closely combines the advantages of the world's advanced technology and Chinese manufacturing industry, adopts a novel design different from the domestic traditional cutting machine, and fully experiences the design principle of "good at core, simple in shape". After the first continuous drum cutter came into being in the middle part of China , we successively developed the sample cutter for the luggage industry and continuous cutting garment sample cutter.
"The competition of enterprises is the competition of talents." GEMEI firmly grasps the trend that the world manufacturing
industry is transferring to the middle part of the world, and has established a research and development team composed of doctors and senior engineers and other high-quality talents,and insists that "innovation" is the eternal power of the development of GEMEI.
1. Q: Are you a manufacturer?
A: Yes, we are specializing in the r&d production for template cutter/inkjet cutter/pen writing cutter/cnc digital fabric cutter/graph plotter in this field for over 10 years.
2. Q: How do you pack these products?
A: Usually packed in wooden case and can pack according to export standard or your requirement.
3. Q: Is it customizable?
A: Yes, We have basic sizes commonly applied in the field and can customize according to your requirements.
4.Q: After-sales service
A: Yes, professional after-sales team and 24-hour technical support by phone, email or skype
5.Q: What is your lead time?
A: Spot goods usually take 2-4 days, and customization takes 5-7 days
