Highlight:
inkjet flatbed cutter plotter printer
, 1500x900mm cutter plotter printer
, apparel flatbed cutter plotter printer
Type: |
Inkjet Printer |
Print Dimension: |
1500*900mm |
Applicable Industries: |
Hotels, Garment Shops, Manufacturing Plant, Retail, Printing Shops, Advertising Company, S hoes/Hats/Bags/Furniture/Car Interiors Producto |
Condition: |
New |
Plate Type: |
Flatbed Printer |
Use: |
Paper Printer, Label Printer, Card Printer, Bill Printer, Cloths Printer, Patterns Template Printer And Cutter |
Automatic Grade: |
Automatic |
Color & Page: |
Single Color |
Voltage: |
AC 220V/110V±10%, 50Hz/3.5KW |
Dimensions(L*W*H): |
1900*1280*800mm |
Weight: |
438 KG |
Warranty: |
1 Year |
Ink Type: |
HP45 Universal Type |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Warranty Of Core Components: |
2 Years |
Core Components: |
Motor, Engine, Drivers And Motherboard |
Cutting Machine Frame And Case: |
Best Flatbed Cutting Plotter Factory Price |
Machine Material: |
All Aluminum Countertops |
Cutting Materials: |
White Paper, Kraft, Plastic Board, Fiberboard, Etc |
Cut Tools: |
HP45 Ink Box,Tungsten Steel Blade |
Cutting Scope: |
1500*900mm |
Cutting Thickness: |
≤3mm |
Cutting Speed: |
1200mm/s Max |
Cutting Machine Size: |
1900*1280*800mm |
Product Name: |
Flatbed Digital Cutting Plotter Universal HP45 Ink Box |
Inkjet Flatbed Cutter Plotter Printer 1500x900mm for Garment Clothing Apparel
Professional garment clothing inkjet apparel printer and plotter designed for high-efficiency production in textile and apparel industries.
Main Features
- Double nozzle high-speed printing with cutting double track tracking system
- Intelligent line subdivision speed control system (linear, arc, sharp, arc)
- Smart identification system for external contour, repeated lines, and cutting priority processing
- Automatic paging with cutting starting point and sequential display system
- Paper jam detection, automatic nozzle cleaning, and machine fault detection system
Specifications
| Model |
GM-1209P3 |
GM-1509P3 |
GM-1510P3 |
GM-1512P3 |
| Effective Cut Area |
1200*900mm |
1500*900mm |
1500*1000mm |
1500*1200mm |
| Product Size (mm) |
1600*1280*1100 |
1900*1280*1100 |
1900*1455*1100 |
1900*1700*1100 |
| Maximum Speed |
1200mm/s |
1200mm/s |
1200mm/s |
1200mm/s |
Medium Attachment: Vacuum Adsorption
Maximum Cut Thickness: 3mm
Cutting Materials: White Paper Board, Kraft Paper, Plastic Board, Red Cardboard, Fiberboard, etc.
Printing Speed: 75㎡/h
Drawing/Cutting: HP45 Ink Cartridge/Special Tungsten Steel Blade
Precision: 0.01mm or less
Transport Port: USB/LAN
Command System: International Standard HP/GL (Compatible with domestic and international CAD online)
Control Interface: LCD Display + Touch Button (Switch between Chinese and English)
Motor/Drive: High-Precision Subdivision Motor, Three-Phase Hybrid Drive
Working Voltage: AC 220V/110V + 10%, 50Hz
Work Environment: Temperature: -30~50℃ / -22~122℉; Humidity: 10%-95% Rh
Cutting Paper: 150g-500g/㎡ recommended (can also cut 50-100g/㎡ paper)
Application Industry: Clothing, Footwear, Luggage, Handbags, Furniture Industries, Car Decoration, Paper Boxes, etc.
Standard Configuration: High Power Suction Air Pump *1; Imported Leather Mesa Pad *1; HP45 Ink Cartridge *2; Special Tungsten Steel Blade *1
Optional Dual-Knife Version
This version enables paper pattern scratching and finishing shaft by switching between full knife and half knife simultaneously. The knife cover can be converted into a pen cover for writing and drawing, providing an economical backup solution when ink cartridges run out.
Product Images
Company Profile
Wuhan Gemei Joint Technology Co., Ltd. is located in the national economic development zone - Wuhan Linkong economic development zone. We specialize in research, development, production, sales and service of automation equipment for clothing, bags and shoes industries. The company carries the mission of "changing traditional industries with high technology" and is committed to providing CAM/CAD integrated solutions for garment, luggage, footwear and other enterprises. Gemei is recognized as a high-tech enterprise and software enterprise in Hubei Province, with "information port" certification and entrepreneurship status for overseas students in Wuhan City.
Since establishment, GEMEI has developed a comprehensive series of cutting machines for clothing, bags, shoes and hats, obtaining multiple software copyright and patent certificates. Based on deep understanding of China's garment, luggage and footwear industries, GM series cutting machines combine Chinese and foreign technological expertise, integrating world advanced technology with Chinese manufacturing advantages. Our innovative design philosophy emphasizes "good at core, simple in shape" and has produced China's first continuous drum cutter, followed by specialized cutters for luggage industry and continuous cutting garment sample cutters. Our R&D team comprises doctors, senior engineers and high-quality talent, with "innovation" as our core development driver.
Packing & Delivery
Exhibition
Certifications
Frequently Asked Questions
Q: Are you a manufacturer?
A: Yes, we specialize in R&D and production of template cutters, inkjet cutters, pen writing cutters, CNC digital fabric cutters, and graph plotters with over 10 years of experience in this field.
Q: How do you pack these products?
A: Products are typically packed in wooden cases according to export standards, with customization available based on your requirements.
Q: Is it customizable?
A: Yes, we offer standard sizes commonly used in the industry and can customize according to your specific requirements.
Q: What about after-sales service?
A: We provide professional after-sales support with 24-hour technical assistance available via phone, email, or Skype.
Q: What is your lead time?
A: Standard products typically ship in 2-4 days, while custom orders require 5-7 days for completion.
