260ml Continuous Ink Tank CAD Printing Plotter with 150-600DPI Resolution and 1900-2500mm Cutting Size

Product Details

Place of Origin: Hubei, China

Brand Name: KAEMI or GM

Payment & Shipping Terms

Price: $1,545.00/sets 1-4 sets

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                260ml continuous ink tank plotter, CAD printing plotter 600DPI, inkjet plotter printer with large tank


Condition:	New	Applicable Industries:	Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Printing Shops, Construction Works , Other, Advertising Company, All Other Fileds Need Cut Cutting Or Printing
Weight (KG):	100	Showroom Location:	Turkey, Viet Nam, Bangladesh, Cambodia
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Marketing Type:	Ordinary Product	Warranty Of Core Components:	1 Year
Core Components:	Motor, Mother Board And Drivers	Warranty:	1 Year, 1 Year Warranty For Full Machine
Product Name:	260ml Ink Tank CAD Printing Plotter VS HP45 Inkjet Plotter	Printing Materials:	White Paper,Kraft, Etc
Cutting Size:	1900mm To 2500mm	Paper Size:	1900mm To 2500mm
Printing Tool:	Universal HP45 Ink Box Or Cartridge	Ink Cartridge Type:	HP45 Ink Box Or Cartridge 2 To 4 Printing Heads Available
Printing Resolution:	150-600DPI, Optional And Settable On Menu	Power Supply Voltage:	220V/50Hz
CAD File Format:	HP-GL

Condition:	New
Applicable Industries:	Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Printing Shops, Construction Works , Other, Advertising Company, All Other Fileds Need Cut Cutting Or Printing
Weight (KG):	100
Showroom Location:	Turkey, Viet Nam, Bangladesh, Cambodia
Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided
Marketing Type:	Ordinary Product
Warranty Of Core Components:	1 Year
Core Components:	Motor, Mother Board And Drivers
Warranty:	1 Year, 1 Year Warranty For Full Machine
Product Name:	260ml Ink Tank CAD Printing Plotter VS HP45 Inkjet Plotter
Printing Materials:	White Paper,Kraft, Etc
Cutting Size:	1900mm To 2500mm
Paper Size:	1900mm To 2500mm
Printing Tool:	Universal HP45 Ink Box Or Cartridge
Ink Cartridge Type:	HP45 Ink Box Or Cartridge 2 To 4 Printing Heads Available
Printing Resolution:	150-600DPI, Optional And Settable On Menu
Power Supply Voltage:	220V/50Hz
CAD File Format:	HP-GL

Product Description

260ml Continuous Ink Tank CAD Printing Plotter with 150-600DPI Resolution

High-performance CAD printing plotter featuring continuous ink tank system and advanced printing technology for professional architectural and engineering applications.

Product Comparison

Key Features

High-speed Servo Control with Full Closed-loop Positioning for accurate output
Independent Output Manager supports automatic file queuing and background printing
Advanced SOPC technology implementation
Breakpoint resume functionality for reliable data transmission
Two-direction high-speed printing capability
Super EPSON 260ml ink box with continuous ink supply system
Easy ink addition operation without ink box replacement
Environmentally friendly and cost-effective operation

Technical Specifications

Type	Big Capacity EP20L Ink Box - Continuous Ink Supply, No Ink Box Replacement
Product Model	EP20-19 \| EP20-21 \| EP20-23 \| EP20-25
Printing Width (cm)	190 \| 210 \| 230 \| 250
Feeding Paper Width (cm)	200 \| 220 \| 240 \| 260
Printing Speed	Two-way high speed 120 m²/h
Printing Format	HPGL drawing language, compatible with domestic and foreign CAD software
Print Resolution	150-600DPI
Type of Nozzle	EP20L
Line Quality	Clear, smooth, no seam, optional 1-8 lines
Nozzle Cleaning	Automatic cleaning before printing
Paper Loading	Front heightening device supports paper roll with diameter of 28cm
Paper Feeding	Hidden infrared precise paper feeding system, continuous 700 meters without deviation
Paper Handling	Unattended automatic paper receiving and feeding
Print Media	40-80g ordinary roll printing paper; 80-250g single brown paper
Communication Interface	Network port, multiple computers can separately control printing
Power Supply	220V/50Hz
Control Panel	Press key operation, simple, convenient, durable
Machine Structure	Die standardized metal structure, high precision and long life
Output Center	Support manual or automatic printing, optional ink-saving mode, support online printing
File Format	HP-GL
Working Temperature	10~35℃ or 50~95℉
Humidity	15%--85% RH (With no Condensation)

Product Gallery

Packaging & Shipping

Company Information

Since its establishment, GEMEI has developed a comprehensive series of cutting machines for clothing, bags, shoes and hats, obtaining numerous software copyright and patent certificates. Based on profound understanding of China's garment, luggage and footwear industry, GM series cutting machines combine the essence of Chinese and foreign technologies, closely integrating world advanced technology with Chinese manufacturing advantages.

Our innovative design differs from traditional domestic cutting machines, fully embodying the "good at core, simple in shape" design principle. After introducing the first continuous drum cutter in central China, we successively developed specialized cutters for the luggage industry and continuous cutting garment sample cutters.

"The competition of enterprises is the competition of talents." GEMEI firmly grasps global manufacturing trends and has established a research and development team composed of doctors, senior engineers, and other high-quality professionals. We insist that "innovation" is the eternal driving force behind GEMEI's development.

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we specialize in R&D and production of template cutters, inkjet cutters, pen writing cutters, CNC digital fabric cutters, and graph plotters with 10 years of experience in this field.

Q: How do you pack these products?

A: Usually packed in wooden cases according to export standards, with customization available based on your requirements.

Q: Is it customizable?

A: Yes, we offer standard sizes commonly used in the field and can customize according to your specific requirements.

Q: What about after-sales service?

A: We provide professional after-sales support with 24-hour technical assistance available by phone, email, or Skype.

Q: What is your lead time?

A: Stock items typically ship in 2-4 days, while custom orders require 5-7 days for production.
